Anti-Static Filter Cotton: Comprehensive Technical Specificatio

• Posted by wang july 3 hours ago Filed in Other #Anti-Static Filter Cotton: Comprehensive Technical Specification  3 views
  click to rate

  1. Material Composition & Properties

  - Base Materials: Specially treated polyester/polypropylene hybrid fibers with permanent anti-static properties

  - Conductive Additives: Carbon fiber threading (0.5-1.2% by weight) for consistent surface resistivity (10⁶-10⁹ Ω/sq)

  - Key Characteristics:

    ✓ Surface charge dissipation <0.1kV/sec (per ANSI/ESD S20.20)

    ✓ Filtration efficiency: 85-95% @ 0.5μm (MERV 13-15 equivalent)

    ✓ Dust holding capacity: ≥300g/m² (per ISO 16890)

    ✓ Flame retardancy: UL94 V-2 rated

  2. Performance Advantages

  - Electrostatic Protection:

    - Prevents spark generation (<3mJ ignition energy)

    - Meets ATEX Directive 2014/34/EU for explosive environments

  - Enhanced Filtration:

    - Three-layer gradient density structure

    - Particle capture down to 0.3μm @ 90% efficiency

  - Operational Economy:

    - Washable up to 50 cycles (with <15% efficiency loss per wash)

    - 40% longer service life vs conventional filters

  3. Industrial Applications

  | Industry          | Application Details                  | Performance Standard               |

  |-------------------|--------------------------------------|------------------------------------|

  | Electronics       | Cleanroom ISO Class 5-6              | IEC 61340-5-1 ESD compliance      |

  | Pharmaceuticals   | Grade C/D sterile areas              | EU GMP Annex 1 requirements       |

  | Food Processing   | Explosion-proof zones (Zone 22)      | FDA 21 CFR 117.40                 |

  | Automotive Paint  | Overspray capture in spray booths    | DIN EN 12981 explosion protection |

  | Aerospace         | Composite manufacturing environments | NAS 1638 Class 5                  |

  4. Maintenance Protocol

  - Cleaning Procedure:

    1. Reverse pulse cleaning @ 4-6 bar

    2. Neutral pH (6.5-7.5) detergent wash

    3. Deionized water rinse (conductivity <10μS/cm)

    4. Ambient temperature drying (<60°C)

  - Replacement Indicators:

    - ΔP ≥350Pa (initial resistance typically 80-120Pa)

    - Visual deformation >5% of original dimensions

    - Surface resistivity >10¹⁰ Ω/sq

  5. Technical Specifications

  - Physical Parameters:

    - Thickness: 15-50mm (customizable)

    - Air permeability: 800-1200L/m²/s @ 200Pa

    - Operating temperature: -40°C to 120°C

  - Certifications:

    - RoHS/REACH compliant

    - ISO 9001/14001 manufacturing

    - UL 900 Class 2 fire rating

  6. Comparative Data

  | Parameter        | Anti-Static Version | Standard Filter |

  |------------------|---------------------|-----------------|

  | Surface Charge   | <100V               | >5kV            |

  | Dust Retention   | +25% capacity       | Baseline        |

  | Wash Cycles      | 50×                 | 15×             |

  | TCO (5-year)     | $0.18/m³            | $0.32/m³        |

  Note: All data based on ASTM F3289 test methodology at 23±2°C, 50±5% RH

  This advanced filtration solution combines ESD protection with high-efficiency particulate arrestance, making it ideal for critical applications where both air purity and electrostatic control are paramount. The material's unique construction meets the most stringent industry requirements while providing superior lifecycle economics.
